INQUIRYProduct Feature
- The aligning accuracy within ±0.01mm, to provide excellent function and improve production yield rate.
- The structure of machine is lighter and stronger, and with the top servo motor and drive motor, more stable, quiet, and fast.
- Provide four post locking system on printing device, to ensure thickness of printing membrane accuracy.
- The servo motor for peeling function and high precision digital constant pressure printing head, to showing constant pressure effect completely.
- Operation by touch panel, easy to set up(setting) and operate, the memory of HMI save conditions of production, and provide other function, such as auto exanimate breakdown and display trouble shooting.
- Provide safety device, such as safety return to origin, auto detect error system, safety optical grating, Emergency switch, alarm light, etc.
- Optional accessory: antistatic bar, anti-dust cover for optical industry.
Product Specification
| Item | Specification |
|---|---|
| Table dimensions | 500x600mm |
| Printing Area(MAX) | 360x360mm |
| Printing Area(MIN) | 150x150mm |
| Frame Dimension(MAX) | 850x850mm |
| Frame Dimension(MIX) | 650x650mm |
| Frame Thickness | 30-40mm |
| Printing Pressure | 1-6kg |
| Main Power | 3Φ, 220V/380V, 50/60Hz |
| Power Consumption | 5.2kw |
| Air Pressure | 6-8kg/cm2 |
| Air Consumption | 60L/Min |
| Dimension | 2400x1400x1900mm (Contain auto loading and unloading device) |
| Weight | 1500kg |
